USB Document Scanner









S500LA4

The S500LA4 is a stylish and affordable document camera with plug-and-play USB power and connectivity designed to meet changing environments.

●



●



●



●



High Speed: The S500LA4 is UVC/UAC compliant with plug and play USB connectivity .​

​

Smart Connectivity & Power: Powered by USB, The S500LA4 can connect to PC or your external display to suit your mixed computing needs.

​



Compact Design: The foldable mechanical arm allows for easy portability, making it convenient to take with you wherever you go.

​



Strong Clarity: The 5MP camera outputs to give you high-resolution images.



Powerful Features for All Your Needs.

Multiformat

Output

Scan Multiple Targets

Scan

Selected Area

Remove Background Color

Video

Recording

High Speed Scan

With our updated software for Windows and Mac, setting up the time from setup to display has never been faster and easier. Build and edit new creative content with powerful editing tools, automatic scanning, cropping, image editing, etc., to achieve information gathering.

document scanner 5MP camera high image built in annotation
document scanner high speed with updated software for Windows and Mac

Strong clarity and versatility

The 5MP camera outputs to give you high resolution images. The built-in annotation feature opens creativity and important information highlights in your scans.

Specification


  • Sensor: CMOS sensor

  • Pixel count: 5MP

  • Frame rate: Max.30fps (display)

  • Output resolution: 2592x1944@20fps(USB), 1280x720(USB),                                               1024x768 (USB), 800x600(USB), 640x480(USB)

  • Image rotation (FW): 0/180

  • Image mirror/freeze: On/Off (default: off)

  • Image white balance/exposure: Auto/manual

  • Image brightness/contrast/saturation:Manual/auto

  • Preview mode: Normal/motion/high quality

  • Video Recording: Yes

Lens Mechanism

  • Image rotation(MD): support

  • Lens: More than 300dpi

  • Shooting area: A4, (210mm x 297mm)

  • Zoom: 20X or 100X digital zoom

  • Color Bit: 24 color bit

  • Focus: Auto

Input/Output Connections

  • USB out: 1 (support display), 1080p

  • USB-A por: USB disk (FAT32, 32GB)

  • USB-b port: 1 (data change to PC, 480Mbps)

  • Built in mic: No

  • Image rotation (FW): 0/180

Function

  • OSD: Yes

  • Debugging mode: Enable/disable debugging mode to capture log file                                     for troubleshoot (default: off)

  • FW update: Can update fw by SW

  • Microscope adapter: N/A

Compatibility

  • USB UVC/UAC compliant: Yes

  • Support SW: Windows/MAC Sphere                                                                                  Lite: Chrome

  • Operating systems(computer): Windows 7, 8,10,11,32&64bit ; Mac                                                            OS 10.13 or above linux;

  • Operating systems(tablet): iOS 11 or above/Android 5.0 or above



Files fomat

  • Word,Word, Excel,Tiff,PDF,JPG

Accessories

  • Cable: USB cable (1.5M)

  • QR code sheet: Yes

Scanning mode

  • Scanning Color Mode: Color, Patterns, Stamps, Gray Scale, B&W

Lighting

  • Light source: Embedded LED light

Others

  • Net dimension: Operation (A4 shooting area),                                                                         (H*W*D) Folded: 98＊85＊310mm

  • Net weight: (0.83kg + 0.3/-0.3kg)

  • Dimension (with package): 380*100*95mm (L*W*H)

  • Gross weight (with package): 0.8kg

  • Power Source: mini-USB in, 5V/0.9A

  • Power consumption: Lamp on: 4W max                                                                                              Lamp off: 3.5W max

  • OCR Language: English, Chinese_TC, Chinese_SC, Japanese, German, Italian, French, Spanish, Finnish, Polish, Russian, Idonesia
